Included are some lightning protection grounding pictures of residential lightning protection systems we have encountered throughout time.
1. LPS Ground Plate Showing Proper Distance From Structure
2. LPS Ground Plate with Warning Tape with Pigtail
3. LPS Downlead to Ground Plate
4. LPS Bond to Steel Ground Rod Clamp
5.) LPS Bond to Ground Plate
6.) LPS Ground Plate with Ground Enhancement Material Around Plate
7.) Ground Terminal
